Fireproof Li/Lead-Acid Charger 72V7A ,6 Protections ,IP20 Dustproof (OEM Supported)

Core Voltage：72V
Output Power：600W ±5%
IP Rating：IP20 (Dust Protected)
Certifications：CE,UL,FCC,GS,KC,PSB,PSE,BMSI,SAA,RCM,ETL,UKCA
Battery Type：Li-ion/Pb Dual Mode
Compatible Devices：E-scooters, Warehouse Robots, Golf Carts，Electric motorcycle, electric bicycle
Environment：Indoor Industrial Use
Protection Features：Spark Proof, Overload Cutoff
OEM Services：Logo Engraving & Custom Color
Warranty：3 Years Warranty
MOQ：100 Units (Bulk Discounts)
Lead Time：20 Days (Expedited Available)

Product Parameters

Input Volt:100-240VAC 50HZ/60HZ		CVCC
Efficiency	88%		Leakage A	<3.5mA
Operating Humidity	5%-95% RH Non-condensing		Altitude	2000m
Operating Temperatue	-20℃—+40℃		Storage Temper	-40℃-+85℃
Safety Certification	FCC,KC,PSE,GS,RCM,UKCA,UL,CCC,CE,CQC,EESS
Suitable battery Type	Lead Acid/LiFePo4/Li-ion/Lipo/Nicd/Nimh/Sodium etc, OEM &ODM
Power on srate	LED is green light
Charging state	LED is Red ligh
Protection	Over Current, Over Voltage, Over temperature, Short Circuit, Reverse Polarity
Output short circuit	The charger will automatically shut down when a shotcircuit occurs on the charger output.			Switch AC power back on and off to restore output
Outprt overvoltage protection	When the DC output voltage≥1.05^*Vout,the charger turms of the outpur.			Switch AC power back on and off to restore output
Output overcurrent protection	When the charger output current ≥1.1*Iout,the charger tums off the output.			Switch AC power back on and off torestore output
Reverse polarity pprotection	When the battery's positive and negative terminals arereversely connected to the charger output, the chargerwill automatically shut down.			Switch AC power back on and off torestore output
Advantage	Low surge current, flyback input full voltage, small output voltage ripple OEM,ODM,5 years warranty Benbv Tech co.,ltd
Package Contents	The packing box contains the product name, model, manufacturer's logo, inspection certificate from the manufacturer's quality department, and the date of manufacture.

Specification and model

LiFePO4	14.6V25A	29.2V20A	43.8V13A	58.4V10A	73V8A	87.6V7A
lithium battery	12.6V25A	29.4V20A	42V14A	54.6V10A	71.4V8A	84V7A
Lead-acid	12V25A	24V20A	36V14A	48V10A	60V8A	72V7A
