Product Overview: High-Efficiency 72V Electric Motorcycle Charger This industrial-grade battery charger is engineered for electric motorcycles, e-bikes, and light EVs requiring a stable 72V charging solution. Unlike standard consumer chargers, this unit features a rugged plastic case designed for durability and heat dissipation, ensuring consistent performance even in demanding environments. It supports a wide range of battery chemistries including LiFePO4, Lithium-ion, and Lead-acid variants.
Product Parameters
| Output short circuit | The charger will automatically shut down when a short circuit occurs on the charger output. | Switch AC power back on and off to restore output | |||||
| Outprt overvoltage protection | When the DC output voltage≥1.05*Vout,the charger turms of the outpur. | Switch AC power back on and off to restore output | |||||
| Output overcurrent protection | When the charger output current ≥1.1*Iout,the charger turns off the output. | Switch AC power back on and off torestore output | |||||
| Reverse polarity protection | When the battery's positive and negative terminals are reversely connected to the charger output, the charger will automatically shut down. | Switch AC power back on and off torestore output | |||||
Specification and model
| LiFePO4 | 14.6V12 A | 29.2V8A | 43.8V5 A | 58.4V4A | 73V3A | 87.6V2.5A |
| lithium battery | 12.6V12A | 29.4V8A | 42V5A | 54.6V4A | 71.4V3A | 84V2.5A |
| Lead-acid | 12V12A | 24V8A | 36V5A | 48V4A | 60V3A | 72V2.5A |
