72V10A Portable Charger w,Cooling Fan, IP20 Waterproof & Fireproof,UL/CE Certified for E-Bikes,Scooters, Li-ion,Pb Battery, 3-Yr Warranty

1.Output: 72V DC / 10A
2.Power Rating: 720W
3.Battery Compatibility: Li-ion/Pb/AGM (Auto-Switching Dual Mode)
4.Operating Temp: -10°C to 40°C (Extreme Weather Proof)
5.Certifications: UL 1310 / CE EN 60335 / FCC Part 15B
6.fire protection: fireproof material
7.Protections: Over-Voltage/Over-Current/Short-Circuit/Reverse Polarity
8.E-Bikes: 500W-1500W Motors
9.Golf Carts: 48V-72V Systems
10.Industrial: AGV Robots/Floor Cleaners
11.Global Voltage: 100-240V AC (For Unstable Grids)
12.Plu

Product Parameters

Input Volt:100-240VAC 50HZ/60HZ		CVCC
Efficiency	92%		Leakage A	<3.5mA
Operating Humidity	5%-95% RH Non-condensing		Altitude	2000m
Operating Temperatue	-10℃—+40℃		Storage Temper	-40℃-+85℃
Safety Certification	FCC,KC,PSE,GS,RCM,UKCA,UL,CCC,CE,CQC,EESS
Suitable battery Type	Lead Acid/LiFePo4/Li-ion/Lipo/Nicd/Nimh/Sodium etc, OEM &ODM
Power on srate	LED is green light
Charging state	LED is Red ligh
Protection	Over Current, Over Voltage, Over temperature, Short Circuit, Reverse Polarity
Output short circuit	The charger will automatically shut down when a shotcircuit occurs on the charger output.			Switch AC power back on and off to restore output
Outprt overvoltage protection	When the DC output voltage≥1.05^*Vout,the charger turms of the outpur.			Switch AC power back on and off to restore output
Output overcurrent protection	When the charger output current ≥1.1*Iout,the charger tums off the output.			Switch AC power back on and off torestore output
Reverse polarity pprotection	When the battery's positive and negative terminals arereversely connected to the charger output, the chargerwill automatically shut down.			Switch AC power back on and off torestore output
Advantage	Low surge current, flyback input full voltage, small output voltage ripple OEM,ODM,5 years warranty Benbv Tech co.,ltd
Package Contents	The packing box contains the product name, model, manufacturer's logo, inspection certificate from the manufacturer's quality department, and the date of manufacture.

Specification and model

LiFePO4	14.6V55 A	29.2V30A	43.8V20A	58.4V15A	73V12A	87.6V10A
lithium battery	12.6V55A	29.4V30A	42V20A	54.6V15A	71.4V12A	84V10A
Lead-acid	12V55A	24V30A	36V20A	48V15A	60V12A	72V10A
